Security Boss MaxSeal Hinged Replacement Flaps


Security Boss MaxSeal Hinged Replacement Flaps

The MaxSeal Hinge Replacement Flap features a heavy-duty hinge flap connection. This hinged flap design allows the flap to travel freely without a pinch point. This means your flaps will last longer in situations of heavy use or if the installed pet door is too low and the pet is hitting the flap connection.

Note: It is very important to install any vinyl flap pet door at least 2" higher than your tallest dog, otherwise they will pinch the flaps at the top of the pet door causing premature wear. The MaxSeal Hinge replacement flaps are a good solution for customers that are experiencing this issue. The flaps are installed into the same holes as your current MaxSeal flaps.

Flap Location:

The interior and the exterior flaps are unique due to the positioning of the metal strikes on each flap. You cannot use an interior flap on the exterior side of your pet door for example. Flaps are UV protected and have embedded nylon cords that run vertically in the material. These flaps are also weatherized to prevent shrinking in sub-zero temperatures.


Custom sizing available - please contact us for more info

Size Flap Size  Rough Opening   Outside Frame Dimensions Shoulder Height Pet Width Breed Example
5" w x 7 1/2" h

8 1/8" w x 9 5/16" h

9 3/8" w x 10 9/16" h

Up to 7"

Up to 4"
Security Boss Pet Door Small Size Cat Door

Cats (only very small)

Small/ Medium 6" w x 9" h 9 1/8" w x 10 3/16" h 10 3/8" w x 12 1/16" h 9" - 13"
Up to 5"
Security Boss Pet Door Small/Medium Door Size

Most Cats, Chihuahua, Dachshund, Mini Poodle

Medium 9" w x 12" h 11 1/8" w x 13 13/16" h 12 3/8" w x 15 1/16" h 12" - 15"
Up to 8"
Security Boss Pet Door Medium Size Dog Door

Terriers, Pug, Corgi, Shiba Inu

Large 11" w x 16" h 13 1/8" w x 17 3/16" h 14 3/8" w x 19 1/16" h 15" - 20"
Up to 10"
Security Boss Pet Door Large Size Dog Door

Basset, Chow, Keeshond, Husky

Tall 11" w x 20" h 13 1/8" w x 21 13/16" h 14 3/8" w x 2 1/16" h 21" - 24"
Up to 10"
Security Boss Pet Door Tall Large Size Dog Door

German Shepherd, Labrador Retriever

Tall Grand 11" w x 25" h 13 1/8" w x 26 3/16" h 14 1/16" w x 26 9/16" h 25" - 27"
Up to 10"
Security Boss Pet Door Tall Grande Dog Door

Standard Poodle, Irish Setter, Greyhound

XL Grand 12" w x 24" h 14 1/8" w x 25 13/16" h 15 3/8" w x 27 1/16" h 25" - 31"
Up to 11"
Security Boss Pet Door XL Grand Size Dog Door

Afghan, Irish Wolfhound, Borzoi

Wide Tall 15" w x 20" h 17 1/8" w x 21 13/16" h 18 3/8" w x 23 1/16" h 22" - 24"
Up to 14"
Security Boss Pet Door Extra Wide Tall Size Dog Door

Rottweiler, Akita, Bulldog

Mammoth 15" w x 24" h 17 1/8" w x 25 13/16" h 18 3/8" w x 27 1/16" h 25" - 27"
Up to 14"
Security Boss Pet Door Mammoth Size dog door

St. Bernard, Newfoundland

Behemoth 15 3/4" w x 32" h 17 7/8" w x 33 13/16" h 19 1/8" w x 35 1/16" h 25" - 31"
Up to 14"
Security Boss Pet Door Behemeth Size Dog Door

Great Dane, Mastiff, Great Pyrenees
