MIM Variogate Single - Crash Tested Gate for Cars


MIM Safe Variogate Single - Car Crash Tested Dog Cargo Barrier Gate for SUVs

The MIM Safe Variogate Single transforms your cargo area into a safe, secure and spacious environment for transporting one pets and maximizing the space in your vehicle. When used with our Universal Cargo Barrier (sold separately) the Variogate will create a safe and secure containment area for your pets, while protecting you and your loved ones. Available in 4 different configurations, see our Sizing tab to find the right size for you.

This single gate is designed to be used on the left side of the vehicle only and comes with a divider to keep you dog separated from other items in your cargo area. Available in standard width and extra wide, as well and short and long depths.  Height is adjustable to fit most vehicles.

Find our Variogate Double Here

How Safe is it?

The Variocage provides comfort and proven safety for your dog as well as the human occupants in your vehicle. When used with our Crash Tested Universal Cargo Barrier the VarioGate System will create a secure containment area to keep you, your passengers and your dog. The VarioGate Single provides useful storage space in your cargo area during travel while keeping your dog or 2 small or medium size dogs safe when they are traveling together.

CERTIFIED - ISO 27955 | ECE R-17 | ECE R-44

MIM Varigate Single Features

  • Fully Adjustable to Fit Most Station Wagons, SUV™s and Minivans
  • Allows Maximum Use of Cargo Area
  • Built-In Key Lock for Security
  • Offers Ventilation When Vehicle is Stationary & Cargo Hatch is Open
  • Doors use Gas Hydraulic Motion Springs for Convenience and Safety
  • Adjustable in Height, Width and Length as well as the Slope for Rear Cargo Door
  • High-Quality, Automotive Grade, Powder Coated Steel Construction
  • Installs Easily in Car with Load Tested Straps to Anchor Points
  • Short and Long Dividers are Available as an Accessory
  • Leash Hooks Included
  • No Modification to Vehicle Required
Installation - No Modification Required

Installing the Variogate is easy and does NOT require modification to your vehicle.  Straps are used to secure the gate to the very back of your vehicle's cargo area, as well as to the deepest part of your cargo area. These can be attached to cargo hooks (if your vehicle has them), seat belt attachments, or other attach points. Further, the Variogat is adjustable in depth, extending from the gate back to the seat behind it adding additional stability.

MIM Variogate Dimensions

Size Variable Width Height Depth - "Short" Depth - "Long" Weight
Standard (3-bar) 21.06 - 28.38 in 21.85 - 37.80 in 30.71 - 39.37 in 41.34 - 59.06 in 29.7lbs
Wide (4-bar) 21.06 - 31.5 in
21.85 - 37.80 in
30.71 - 39.37 in
41.34 - 59.06 in 30.3lbs

Variogate Single Sizing guide

Model Comparison Chart

Variocage Single Variocage Double Variocage MinMax Variocage Compact Variogate
MIM Safe Variocage Single Crash Tested Car Travel Crate for Dogs MIM Variocage Double Crash Tested two Dog Car Travel Crate MIM Variocage Minimax Crash Test Travel Crate for Small dogs or cats MIM Variocage Compact Crash Test Travel Crate for hatchbacks MIM Variogate Crash Tested Dog Travel Gate for SUVs
For Single Dogs For Two Dogs or Very Large Pets For Small Dogs or Cats For Station Wagons, Hatchbacks or similar Universal Gate for use with Most SUVs and Wagons
The MIM Variocage Single is designed for one dog and is proven to provide protection to you and your pet while still leaving sufficient space for other cargo in your vehicle. Available in 6 adjustable si

The MIM Safe Variocage Double is the largest Variocage offered and is built for two dogs, and the movable center divider is easily adjustable if one dog needs more space. This divider can be removed and the crate used for one dog. Available in 8 adjustable sizes.

Variocage MiniMax is designed with all of the safety features of the larger models, scaled down to protect smaller pets. Its bars are closer together to prevent smaller dogs and cats from escaping or poking their heads out between bars during transit. The smaller footprint also leaves considerable space for additional cargo.
The Variocage Compact is designed for use in vehicles that have a threshold (or sill) at the rear cargo door, such as hatchbacks, station wagons, minivans or similar. The Variocage Compact features a raised front door which is designed to clear the vehicle threshold without requiring special mounting or a platform. Its small footprint leaves considerable space for additional cargo.
The Variogate Transforms your cargo area into a safe and very practical environment for transporting pets and maximizing the space in your vehicle.  When used with our Universal Cargo Barrier the Variogate will create a safe and secure containment area for your pets.
View Single Crate View Double Crate View MinMax Crate View Compact Crate View Variogate

Fit Guarantee

Call today and speak to one of our Experts! When you contact us directly with accurate measurements to verify the correct size Variocage for your pets and vehicle, you will receive a Fit Guarantee. With this guarantee, Adeo Pets will accept full responsibility for exchanges and/or returns for any Variocage that does not fit properly.  For all other returns, please see our Return Policy

Three (3) Year Manufacturer Warranty

4x4 North America, Inc. warranties all MIM Construction and Variocage Products for Three (3) years from date of purchase. To be covered by the warranty, the defect must be an original manufacturing defect. The warranty does not cover any damage, mis-use or modifications by consumers nor does it cover damage from animals, drops, falls or impacts.

MIM Variogate Measuring & Sizing Instructions

Use the detailed image and sizing chart to find the correct Variogate for your vehicle.  Please contact us BEFORE ordering, our experts will help ensure proper fit and provide you a Fit Guarantee

MIM Variogate Measuring Guide

MIM Variogate Dog Cargo Barrier for SUVs and Cars Sizing and Measuring Guide

MIM Variogate Sizing Chart Variogate Single Car Sizing Chart

MIM Variogate Assembly Guide

Please download and follow your assembly guide to properly install your Variocage

MIM Variogate Single Assembly Guide

MIM Products Ship via FedEx Ground  from Missouri - *Signature Required*

  • Items normally ship within 1-2 business days after order is placed.
  • If your item is delayed or not in stock, we will contact you directly.
  • See map below to estimate transit time to your location
  • *All Variogates ship FedEx Direct Signature Required

MIM Variocage US Shipping transit time

Fast Shipping

We do our best to ship FAST and make it easy for you.  At the top of this page, we have noted how long it normally takes to process and ship your order.  You can then use the map above to estimate delivery times.  We will send you an email confirmation with the tracking number as soon as your order ships

Please see our Shipping Policy for full details.

Easy Returns

Things don't always work out, we get it.  We'll do our very best to make your return simple and easy. Please email us and we'll provide all the return instructions for your specific item. Please call us before ordering and we will guarantee fit to your vehicle.  Without calling before purchase, we cannot accept returns due to sizing.

Please see our Return Policy for full details.

My vehicle does not have cargo hooks, can I still use this gate?

Most vehicles have hooks or attach points in the cargo area, sometimes these can be hard to find as they are hidden behind seats or under small latch covers. If you cannot find any cargo hooks look for other areas to attach your gate like seatbelt hooks. If you are looking for a stronger fitment, consider adding the Variobarrier, this unit is specifically designed to allow the Variogate to attach into it's base making it a stronger more complete unit together.
